Q345B 16Mn galvanize tiyo asye
Longè: 5.5m, 5.8m, 6m, 11.8m, 12m oswa jan ou mande
Kouch zenk: Pre-tiyo asye galvanize: 20-275g/m2
Zenk kouch: cho plonje tiyo asye galvanised: 180-500g / m2
Ekspozisyon pwodwi
Enfòmasyon sou pwodwi
|
Non pwodwi |
Q345B 16Mn galvanize tiyo asye |
|
Non ki gen rapò |
Cho woule galvanize tiyo asye, frèt woule galvanize tiyo asye, HDG tiyo, HDG Tib, plonje cho galvanize tiyo, SCH tiyo, ASME Tib |
|
Epesè miray la |
0.3mm-30mm |
|
Longè |
5.5m, 5.8m, 6m, 11.8m, 12m oswa jan ou mande |
|
Tolerans |
Epesè miray: ± 0.05mm Longè: ± 6mm Eksteryè Dyamèt: ± 0.3mm |
|
Zenk kouch |
Pre-tiyo asye galvanize: 20-275g/m2 Cho plonje galvanised tiyo asye: 180-500g / m2 |
Tablo orè tiyo a nan tiyo asye galvanize
Tablo sa a montre epesè miray orè a nan tiyo asye galvanised Jingtong.
|
Tiyo nòmal |
OD (mm) |
Nòmal epesè miray (mm) |
|||||||||||||
|
DN |
pous |
ASME |
SCH10 |
SCH20 |
SCH30 |
STD |
SCH40 |
SCH60 |
XS |
SCH80 |
SCH100 |
SCH120 |
SCH140 |
SCH160 |
XXS |
|
15 |
1/2 |
21.3 |
2.11 |
|
2.41 |
2.77 |
2.77 |
|
3.73 |
3.73 |
|
|
|
4.78 |
7.47 |
|
20 |
3/4 |
26.7 |
2.11 |
|
2.41 |
2.87 |
2.87 |
|
3.91 |
3.91 |
|
|
|
5.56 |
7.82 |
|
25 |
1 |
33.4 |
2.77 |
|
2.9 |
3.38 |
3.38 |
|
4.55 |
4.55 |
|
|
|
6.35 |
9.09 |
|
32 |
1.25 |
42.2 |
2.77 |
|
2.97 |
3.56 |
3.56 |
|
4.85 |
4.85 |
|
|
|
6.35 |
9.7 |
|
40 |
1.5 |
48.3 |
2.77 |
|
3.18 |
3.68 |
3.68 |
|
5.08 |
5.08 |
|
|
|
7.14 |
10.15 |
|
50 |
2 |
60.3 |
2.77 |
|
3.18 |
3.91 |
3.91 |
|
5.54 |
5.54 |
|
|
|
8.74 |
11.07 |
|
65 |
2.5 |
73 |
3.05 |
|
4.78 |
5.16 |
5.16 |
|
7.01 |
7.01 |
|
|
|
9.53 |
14.02 |
|
80 |
3 |
88.9 |
3.05 |
|
4.78 |
5.49 |
5.49 |
|
7.62 |
7.62 |
|
|
|
11.13 |
15.25 |
|
90 |
3.5 |
101.6 |
3.05 |
|
4.78 |
5.74 |
5.74 |
|
8.08 |
8.08 |
|
|
|
|
|
|
100 |
4 |
114.3 |
3.05 |
|
4.78 |
6.02 |
6.02 |
|
8.56 |
8.56 |
|
11.13 |
|
13.49 |
17.12 |
|
125 |
5 |
141.3 |
3.4 |
|
|
6.55 |
6.55 |
|
9.53 |
9.53 |
|
12.7 |
|
15.88 |
19.05 |
|
150 |
6 |
168.3 |
3.4 |
|
|
7.11 |
7.11 |
|
10.97 |
10.97 |
|
14.27 |
|
18.26 |
21.95 |
|
200 |
8 |
219.1 |
3.76 |
6.35 |
7.04 |
8.18 |
8.18 |
10.31 |
12.7 |
12.7 |
15.09 |
18.26 |
20.62 |
23.01 |
22.23 |
|
250 |
10 |
273 |
4.19 |
6.35 |
7.8 |
9.27 |
9.27 |
12.7 |
12.7 |
15.09 |
18.26 |
21.44 |
25.4 |
18.58 |
25.4 |
|
300 |
12 |
323.8 |
4.57 |
6.35 |
8.38 |
9.53 |
10.31 |
14.27 |
12.7 |
17.48 |
21.44 |
25.4 |
28.58 |
33.32 |
25.4 |
|
350 |
14 |
355.6 |
6.35 |
7.92 |
9.53 |
9.53 |
11.13 |
15.09 |
12.7 |
19.05 |
23.83 |
27.79 |
31.75 |
35.71 |
|
|
400 |
16 |
406.4 |
6.35 |
7.92 |
9.53 |
9.53 |
12.7 |
16.66 |
12.7 |
21.44 |
26.19 |
30.96 |
36.53 |
40.19 |
|
|
450 |
18 |
457.2 |
6.35 |
7.92 |
11.13 |
9.53 |
14.27 |
19.05 |
12.7 |
23.83 |
39.36 |
34.93 |
39.67 |
45.24 |
|
|
500 |
20 |
508 |
6.35 |
9.53 |
12.7 |
9.53 |
15.09 |
20.62 |
12.7 |
26.19 |
32.54 |
38.1 |
44.45 |
50.01 |
|
|
550 |
22 |
558.8 |
6.35 |
9.53 |
12.7 |
9.53 |
|
22.23 |
12.7 |
28.58 |
34.93 |
41.28 |
47.63 |
53.98 |
|
|
600 |
24 |
609.6 |
6.35 |
9.53 |
14.27 |
9.53 |
17.48 |
24.61 |
12.7 |
30.96 |
38.89 |
46.02 |
52.37 |
59.54 |
|
|
650 |
26 |
660.4 |
7.92 |
12.7 |
|
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
700 |
28 |
711.2 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
750 |
30 |
762 |
7.92 |
12.7 |
15.88 |
9.53 |
|
|
12.7 |
|
|
|
|
|
|
|
800 |
32 |
812.8 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
850 |
34 |
863.6 |
7.92 |
12.7 |
15.88 |
9.53 |
17.48 |
|
12.7 |
|
|
|
|
|
|
|
900 |
36 |
914.4 |
7.92 |
12.7 |
15.88 |
9.53 |
19.05 |
|
12.7 |
|
|
|
|
|
|
Baj popilè: q345b 16mn galvanised tiyo asye, Lachin q345b 16mn galvanised tiyo asye manifaktirè, Swèd, faktori
